FULIN AUTO-ALCOHOL DAMPENING SYSTEM

FULIN AUTO-ALCOHOL DAMPENING SYSTEM
In tinplate lithographic printing process, since tinplate has no absorption of water brought by the rubber drum, the water is easily trapped between the rollers. With the ordinary dampening system, it is difficult for the operator to master the water-ink balance in the iron printing process.
Due to the small dosage of dampening liquid of the alcohol dampening system, the working temperature of the layout is low, and the alcohol concentration is constant, which improves the effect of printing quality and protects the surface of the PS plate and makes the printing surface bright and clean; The W4 roller of the alcohol dampening system can swing and string left and right between the dampening roller and the inking roller, adjusting it can make the dampening plate on the dampening roller more uniform, and can also remove the waterline of the printing surface, printing ghosting and ink chips and other product defects. The non-absorbency of tinplate makes the traditional water-dampening solution easy to stay between the rollers to cause ink emulsification, and the alcohol dampening system plays a certain role in maintaining the printing suitability of the ink and reducing the emulsification of the ink. The continuous water transfer of the alcohol dampening system can also avoid the uneven distribution of dampening liquid and the water bar failure easily caused by intermittent effluent.
The dampening liquid is transmitted through three water rollers, continuously and evenly transferred to the PS version, and the W3 roller is driven by a variable speed motor, which is transmitted in a certain proportion between it and the W2 roller, and the W1 roller is driven by the printing plate hobbing, and the motor speed of the W3 roller is generally adjusted to change the liquid volume when adjusting the liquid volume. Its structure design is simple and easy to operate.
The rotation ratio of each water roller of the alcohol dampening system is different, the transmission ratio of the roller and the dampening roller is 1:0.8 is the ideal state, the transmission amount of dampening liquid is uniform regardless of how the linear speed changes, so that the water-ink balance meets the printing quality requirements, in addition, this ratio of combination also has the role of protecting the surface of the PS plate; The surface of the PS version is cleaned to remove residual impurities and ink, so that the printing surface is bright and clean; The ordinary water glue dampening plate, the layout is easy to get dirty, and the distribution of the dampening liquid is uneven, which seriously affects the quality of the printed matter.
Fulin alcohol dampening system will reduce frequency of the ink emulsification, printing ghosting, dirty plate, water pattern and other common phenomena in tinplate printing process and basically overcome the quality defects caused by use of ordinary dampening system. It minimize the consumption of ink, improve pattern clarity with strong dots and bright colors, and as a significant role to promote the economic benefits of printing
